Working pressure：0.3-0.8MPa

Clamping force（ under 0.6Mpa）：1000N

Operating temperature: Normal temperature：-20-60℃

High temperature：-20~200℃

Locking/opening：0.2s

Weight：1kg

Max. blank thickness：3mm

Self-locking function：Yes

Cylinder joint size：2-G1/8

Application：Extended flat clamp with long clamp arm and thin lower clamp arm, the clamping distance is farther, suitable for small space reserved for clamping in the die
